Cat 304E
Make Caterpillar Model 304E CR Year 2015 Hours 3,830 Price $36,400 New/Used Used Stock Number C138390 Operating Weight 8,838 Horsepower 40 Dimensions Height – Over Cab 8.2ft in Maximum Cutting Height – Long Stick 16.7ft in Maximum Cutting Height – Standard Stick 16.4ft in Maximum Digging Depth – Standard Stick 10.3ft in Maximum Dump Height […]
Description
Make
Caterpillar
Model
304E CR
Year
2015
Hours
3,830
Price
$36,400
New/Used
Used
Stock Number
C138390
Operating Weight
8,838
Horsepower
40
Height – Over Cab
8.2ft in
Maximum Cutting Height – Long Stick
16.7ft in
Maximum Cutting Height – Standard Stick
16.4ft in
Maximum Digging Depth – Standard Stick
10.3ft in
Maximum Dump Height – Long Stick
12.1ft in
Maximum Dump Height – Standard Stick
11.8ft in
Maximum Horizontal Reach – Long Stick
18ft in
Maximum Horizontal Reach – Standard Stick
17.11ft in
Maximum Reach – Ground Level – Standard Stick
17.61ft in
Maximum Vertical Dig Depth – Long Stick
8.4ft in
Maximum Vertical Dig Depth – Standard Stick
8ft in
Shipping Height
8.2ft in
Shipping Length
15.8ft in
Track Shoe Width
1.11ft in
Transport Width
6.4ft in
Machine Swing Speed
9rpm
Boom Swing – Left – Without Stop
80degrees
Boom Swing – Left – With Stop
55degrees
Boom Swing – Right
50degrees
Gross Power
42hp
Net Power
40hp
Engine Model
Cat C2.4
Operating Weight
8497lb
Operating Weight – With Cab
8838lb
Height
12.8in
Width
6.4ft in
Lift Height
15.8in
Dig Depth
18.5in
Operating Pressure – Swing
2625 psi
Operating Pressure – Equipment
3553 psi
Operating Pressure – Travel
3553 psi
Digging Force – Stick – Standard
4856lb
Digging Force – Stick – Long
4384lb
Digging Force – Bucket
8498lb
Auxiliary Circuit – Primary
15.9 gal/min
Auxiliary Circuit – Secondary
7.1 gal/min
Cooling System
1.7gal
Fuel Tank
12.2gal
Hydraulic Tank
11.2gal
Hydraulic System
17.2gal
Engine Oil
2.5gal
Bore
3.4in
Stroke
4in
Displacement
146cu in
Msc Spec Date
3/06
Maximum Traction Force – High Speed
3777lb
Maximum Traction Force – Low Speed
6921lb
Travel Speed – High
2.8mph
Travel Speed – Low
1.6mph
